YD520C 15Amp 125 Volt AC 2-POLE,3-WIRE GROUNDING  American Industrial nema receptacle

YD520C 15Amp 125 Volt AC 2-POLE,3-WIRE GROUNDING American Industrial Grade Straight Blade female Connector NEMA 5-20R

  • Model number: YD520C

  • NEMA Configuration: NEMA 5-20 R

  • Rated Current/Voltage: 20A 125V

  • Certificate: UL / cUL (UL No: E350413)

  • Sample day: 1-3 days

  • Lead time: 8-15 days

  • Guarantee: 365 days

Production details

Basic Information

Product Item

 Straight Blade female Connector

Model number

YD520C

NEMA Configuration

NEMA 5-20R

Wiring Scheme

2 Pole, 3 Wire Grounding

Amperage

20 Amp

Voltage

125V AC

Color

Black

Blade Holder Material

Gray Polycarbonate

Retainer Material

Clear Polycarbonate

Housing Material

Nylon-Black

Cord Clamp Material

Nylon-Black

Blade Material

Brass

Terminal Screw Material

#8-32 Brass

Ground Screw Material

#8-32 Brass(Green)

Contact Holder Material Nylon- Natural
Power Contacts Material .040”(1.0m/m)Copper Alloy

Flammability

UL 94 V-0

Listings

UL/cUL  E350413

Rohs Compliant

Yes

Shipping way

by air/sea/express

Place of Origin

Guangdong, China (Mainland)

Sample day

1-3 days

Mass order Lead time

8-15days





Advantages

1.100% full copper pin
2. Own international certificates.
3. Strictly quality control in the production processing.
4. Eco-friendly, Durable, Safety and Portable and so on.
5. Provide one-year guarantee service.
6. OTD up to 100%.

How to buy from us?

1. Please confirm the Products and quantities that you would like to purchase by contacting our sales persons.
2. We will send you a Proforma Invoice once we get your order list, and will help you calculate the best freight charge, by courier, by air or by sea if required.
3. After you send us the payment, please provide the bank copy if possible, so that we can start to arrange production asap.
4. As soon as the goods are shipped out, we will let you know the tracking number.
5. For after sales-service. Please contact the sales persons directly or contact us.

Trade Condition

1. MOQ: 100 pcs / per model after sample order.

2. Payment Terms: T/T, Paypal and L/C for option.

a. By T/T: Bank transfer to YUADON company bank account
b. By Paypal: There will be 4% of total price as paypal fee.
c. By L/C(letter of credit): the order is more than USD10,000.

3. Shipment

We have a Strong cooperation with our forwarder, so we will give a best shipping cost to you
A. For small order, ship by DHL, EMS, UPS, FedEx international express.
B. For big order, ship by Air or by Sea.
